Repeat AM32 Dual Brushless Drive ESC

Features

• V1.1 comes with castellated pads for soldering the motors to
• Pre-programmed with drive settings
• Small size – 28 x 20 x 5 mm
• Light Weight – (6g with signal wires)
• Active current limiting on each channel (Comes with current limit set at 10A)
• 2-6S voltage capacity
  • Comes with capacitor for 6S usage
• Comes with BEC to power your receiver
• Power pads on both sides of the board allow you to solder your weapon ESC to the bottom side of the board
• Equivalent components to 45A drone ESCs
• Does not have mixing ability
• Suitable for 1lb to 3lb robots
  • Suggested 4A-8A current limit for 1lb-3lb robots
  • Can be used in larger robots with appropriate current limits
